Downtown LED Outdoor Square Flushmount

AC LED technology - no driver or transformer required.
Easily fits on a pancake junction box.
Built in color-temperature adjustable
This fixture is factory pre-set to the CCT ordered and can be modified in the field with the flick of a switch.
Material: Aluminum
Shade Material: Glass
Dimmable: Yes
Dimmer Not Included
Dimmer Type: ELV or TRIAC dimmer
Lighting Style: Downlight
Location Rating: ETL Listed Damp
Dark Sky Compliant: This design is compliant with International Dark Sky Association standards to reduce outdoor light pollution.
Title 20 Compliant: This design is compliant with California's rigorous Title 20 energy efficiency mandate.
Title 24 Compliant: This design is compliant with California's expansive Title 24 energy use regulations.
OK for Outdoor Use
Warranty: 5 Years Functional, 2 Years Finish
Made In China

• Finish: Black, White

• Color Temperature: 3000, 3500, 4000

Fixture: Width 5", Height 4.5", Depth 5", Weight 5.57Lbs

Compare Brightness:

How many lumens do you need?

More lumens = more light

Lumens
1600
1100
800
450

=

Incandescent	LED	Fluorescent	Halogen
100 W	22 W	23 W	72 W
75 W	18 W	18 W	53 W
60 W	12 W	13 W	43 W
40 W	9 W	11 W	29 W

Output & Wattages based on most common products available for each medium screw-based light bulb. Actual output may vary by product.

Lumens

The amount of light that comes from a bulb, which has commonly been measured in watts. The more lumens, the brighter the bulb.

Wattage

A measurement of the power delivered to a component of an electric circuit (allowing a one-ampere current to flow through the component under the pressure of 1 volt.)

Bulb Shape

Bulb shapes are denoted with a letter, which describes the shape, and a number, which indicates the size. The number indicates the diameter of the light bulb at its widest part in eighths of an inch.

Base

The part of the bulb that connects to the fixture and its power supply. Bulb bases are denoted with the letter E, and a number which indicates the diameter of the bulb base at its widest part in millimeters.

Voltage

Indicates how much voltage a bulb can accept via the fixture it's installed in.

Light Color Temperature

The relative color from a light source, measured on the Kelvin temperature scale. Warm light is lower in color temperature (2700-3000 K) and cool, blue light is higher (5000 K).

Average Rated Life

The average amount time that a bulb is expected to last.

CRI

CRI = color rendering index. This number, which can go from 0 to 100, measures the ability of a light or bulb accurately renders colors. The higher the number, the better, with most quality bulbs these days measuring at least in the 80s.

Manufacturer IDs: view

FM-W47206-30-BK FM-W47206-35-BK FM-W47206-40-BK FM-W47206-30-WT FM-W47206-35-WT FM-W47206-40-WT
