Corona LED Ring Pendant Light

Designed by Robert Sonneman
Commercial and/or Residential Use
Comes with 6" adjustable cable
6", 16", and 48" options are also dimmable with standard incandescent (TRIAC) dimmer
6" and 16" options are 120VAC input w/ LED driver
24", 32", and 48" options are 100-277VAC input w/ LED driver
Material: Metal
Shade Material: Acrylic
Dimmable: Yes
Dimmer Not Included
Sloped Ceiling Adaptable: No
Installation Type: Hardwired
Lighting Style: Soft/Diffused/Ambient
Location Rating: ETL Listed
Title 20 Compliant: This design is compliant with California's rigorous Title 20 energy efficiency mandate.
Title 24 Compliant: This design is compliant with California's expansive Title 24 energy use regulations.
Not OK for Outdoor Use
Assembly Required: Yes
Warranty: 5 Years
Made In China

• Finish: Bright Satin Aluminum, Satin Black

• Size: Mini, Small, Medium, Large, Extra Large

• Color Temperature: 3000, 3500

Mini Option Canopy: Diameter 5"
Mini Option Fixture: Height 2", Diameter 6", Weight 3Lbs
Mini Option Maximum Hanging: Length Adjustable From 6", Adjustable To 72"
Small Option Canopy: Diameter 5"
Small Option Fixture: Height 2", Diameter 15.75"
Small Option Maximum Hanging: Length 74"
Medium Option Canopy: Diameter 5"
Medium Option Fixture: Height 2", Diameter 23.75", Weight 6Lbs
Medium Option Maximum Hanging: Length Adjustable From 14", Adjustable To 72"
Large Option Canopy: Diameter 5"
Large Option Fixture: Height 2", Diameter 31.5", Weight 9Lbs
Large Option Maximum Hanging: Length Adjustable From 18", Adjustable To 72"
Extra Large Option Canopy: Diameter 8"
Extra Large Option Fixture: Height 2.5", Diameter 48", Weight 13Lbs
Extra Large Option Maximum Hanging: Length Adjustable From 21", Adjustable To 72"

Compare Brightness:

How many lumens do you need?

More lumens = more light

Lumens
1600
1100
800
450

=

Incandescent	LED	Fluorescent	Halogen
100 W	22 W	23 W	72 W
75 W	18 W	18 W	53 W
60 W	12 W	13 W	43 W
40 W	9 W	11 W	29 W

Output & Wattages based on most common products available for each medium screw-based light bulb. Actual output may vary by product.

Lumens

The amount of light that comes from a bulb, which has commonly been measured in watts. The more lumens, the brighter the bulb.

Wattage

A measurement of the power delivered to a component of an electric circuit (allowing a one-ampere current to flow through the component under the pressure of 1 volt.)

Bulb Shape

Bulb shapes are denoted with a letter, which describes the shape, and a number, which indicates the size. The number indicates the diameter of the light bulb at its widest part in eighths of an inch.

Base

The part of the bulb that connects to the fixture and its power supply. Bulb bases are denoted with the letter E, and a number which indicates the diameter of the bulb base at its widest part in millimeters.

Voltage

Indicates how much voltage a bulb can accept via the fixture it's installed in.

Light Color Temperature

The relative color from a light source, measured on the Kelvin temperature scale. Warm light is lower in color temperature (2700-3000 K) and cool, blue light is higher (5000 K).

Average Rated Life

The average amount time that a bulb is expected to last.

CRI

CRI = color rendering index. This number, which can go from 0 to 100, measures the ability of a light or bulb accurately renders colors. The higher the number, the better, with most quality bulbs these days measuring at least in the 80s.

• Dust with a soft dry cloth.

Manufacturer IDs: view

2311.16 2311.25 2313.16 2313.25 2315.16 2315.25 2317.16 2317.25 2318.16 2318.25 2318.16-35 2317.16-35 2318.25-35 2317.25-35

California Residents: Prop 65 regulations
