Key Features
Ships To Canada
Dimmable
Contract Grade
Energy Star Qualified
Limited 5 Year Functional, 2 Year Finish warranty
Made in China
With its minimalist form and high output energy-efficient lighting, the Volo LED Linear Pendant by dweLED is the perfect lighting solution for contemporary residential and commercial settings. Its linear form consists of a Die-cast Aluminum body (with rounded ends) that contains a Frosted Acrylic diffuser and integrated LEDs. Though slim in appearance, the fixture’s lighting is robust, providing a pleasant, even illumination that can be used for your next dinner or office meeting.
Item Number
DWE694478
.
MFR ID
PD-22754-AL
Volo LED Linear PendantTechnical Files and Diagrams
Diagrams
Volo LED Linear Pendant Technical Files and Diagrams
Diagrams
Dimensions
- 54-Inch Option CanopyLength 13.75", Width 5", Height 1"
- 54-Inch Option FixtureLength 54", Width 1.5", Height 3.25"
- 54-Inch Option Maximum HangingLength Adjustable To 85"
Details
- MaterialAluminum
- DimmableYes
- DimmerNot Included
- Dimmer TypeELV or TRIAC or 0-10V
- FinishBrushed Aluminum
- Location RatingETL Listed Damp
- Title 24This design is compliant with California's expansive Title 24 energy use regulations.
- Energy Star QualifiedRated energy efficient by the Environmental Protection Agency.
- Not OK for Outdoor Use
- Assembly RequiredNo
- WarrantyLimited 5 Year Functional, 2 Year Finish
- Made InChina
- Lighting StyleIndirect
- Minimalist design
- Rounded end caps
- Frosted Acrylic diffuser
- Dimmable from 100-10% with an ELV dimmer (not included)
- Rectangular canopy with push-pin locking mechanism
- Transformer located inside the canopy
- Dimmer Range: 100% - 5%
- Total Lumens3095.0
- Volts120/240/277
- Color Temp3000 (Soft White)
- Lamp TypeLED Built-in
- CRI90
- Equivalent Halogen, CFL or LED Bulb Can Be UsedNo
- Total Wattage56.00
- Average Lifespan (Hours)54,000
Manufacturer IDs:
California Residents:
Rated 5.0 out of 5 stars
7
2023-07-31
beautiful modern light fixture
Rated 5 out of 5 stars
we used this over our kitchen island on a dimmer and absolutely love it. It matches our brushed aluminium look of our appliances so well. It's incredibly bright when needs to be or dim down to nearly nothing if you'd like. The width of the light is much slimmer than I thought it would be which isn't a bad thing since the diffuser disperses light well. It's actually so thin that upon friends/family walking into the house no one even notices it at all. I find this great as it does not look cumbersome.
SteveH · 2020-01-18
Helpful: 1 Not helpful: 0
Sleek Modern Look
Rated 5 out of 5 stars
We bought the 75" light in black, and it looks great and so far is performing well. We had to adjust the height of it as it was hanging too low out of the box, but electricians seemed to be able to handle it without too much difficulty. Very important to make sure you get the correct dimmer switch type. We initially installed a standard dimmer and it flickered badly. We were about ready to send it back when we reread the specs and it called out the ELV dimmer. We replaced it and now it works correctly. ELV dimmers are more expensive, so factor that in to your overall cost.
supercabas · 2021-01-02
Helpful: 0 Not helpful: 0
Perfect dining room light fixtureq
Rated 5 out of 5 stars
We have purchased two of the 54" versions of this fabulous fixture. It has a very contemporary design. The color temperature is beautiful and throws an even light over the entire table. When one is sitting at the table there is very little or no glare to the eye. Wish we could use it more places!
Pranji · 2021-01-28
Helpful: 0 Not helpful: 0
Perfect task lighting
Rated 5 out of 5 stars
Great style and quality. Easy to install and level the cables with the tension cable locks. The level of lumens and CRI make it perfect for spot lighting ove our kitchen prep area.
JasoninDenver · 2018-12-22
Helpful: 1 Not helpful: 0
Looks great!!
Rated 5 out of 5 stars
5 Star Review
Hannah · 2019-08-06
Helpful: 0 Not helpful: 0
