Ulta Thin 4 Inch LED Wafer Downlight

Designed in 2019
Edge-lit LED technology
No housing required
Allows for easy retrofit, remodel or new construction installation from below the ceiling
FT4 plenum-rated cable connector to connect from module to remote driver box
IC-rated driver with two remote selectable color temperature options
Isolated driver integrated inside steel remote box with four 7/8" knockouts with slots for pryout
Steel spring clip for easy installation
Suitable for pulling wires with a 12 cubic-inch wiring compartment to accommodate up to (6) 14 gauge insulated conductors for daisy-chain applications
Suitable for installation in t-grid and drop ceiling applications
3" plenum space required for installation of the remote driver box
CSA Certified
Material: Aluminium
Shade Material: Polycarbonate
Dimmable: Yes
Dimmer Not Included
Dimmer Type: Electronic low voltage (ELV)
Lighting Style: Downlight
Location Rating: CSA Certified
Title 24 Compliant: This design is compliant with California's expansive Title 24 energy use regulations.
ENERGY STAR® Certified: Rated energy efficient by the Environmental Protection Agency.
OK for Outdoor Use
Warranty: Limited 5 Year
Made In China

• Finish: Brushed Nickel, Matte Black, Matte White, Oil Rubbed Bronze

• Size: 4 in, 6 in

• Color Temperature: 3000, 4000

4 in Option Trim: Height 1.1", Diameter 3.2", Weight 1Lbs
6 in Option Trim: Height 1.1", Diameter 6.7", Weight 1.5Lbs

Compare Brightness:

How many lumens do you need?

More lumens = more light

Lumens
1600
1100
800
450

=

Incandescent	LED	Fluorescent	Halogen
100 W	22 W	23 W	72 W
75 W	18 W	18 W	53 W
60 W	12 W	13 W	43 W
40 W	9 W	11 W	29 W

Output & Wattages based on most common products available for each medium screw-based light bulb. Actual output may vary by product.

Lumens

The amount of light that comes from a bulb, which has commonly been measured in watts. The more lumens, the brighter the bulb.

Wattage

A measurement of the power delivered to a component of an electric circuit (allowing a one-ampere current to flow through the component under the pressure of 1 volt.)

Bulb Shape

Bulb shapes are denoted with a letter, which describes the shape, and a number, which indicates the size. The number indicates the diameter of the light bulb at its widest part in eighths of an inch.

Base

The part of the bulb that connects to the fixture and its power supply. Bulb bases are denoted with the letter E, and a number which indicates the diameter of the bulb base at its widest part in millimeters.

Voltage

Indicates how much voltage a bulb can accept via the fixture it's installed in.

Light Color Temperature

The relative color from a light source, measured on the Kelvin temperature scale. Warm light is lower in color temperature (2700-3000 K) and cool, blue light is higher (5000 K).

Average Rated Life

The average amount time that a bulb is expected to last.

CRI

CRI = color rendering index. This number, which can go from 0 to 100, measures the ability of a light or bulb accurately renders colors. The higher the number, the better, with most quality bulbs these days measuring at least in the 80s.

Manufacturer IDs: view

WF6 LED 30K40K50K 90CRI BN M6 WF4 LED 30K40K50K 90CRI BN M6 WF6 LED 30K40K50K 90CRI MW M6 WF6 LED 27K30K35K 90CRI MW M6 WF4 LED 30K40K50K 90CRI MW M6 WF4 LED 27K30K35K 90CRI MW M6 WF6 LED 30K40K50K 90CRI ORB M6 WF4 LED 30K40K50K 90CRI ORB M6 WF4 LED 27K30K35K 90CRI ORB M6 WF6 LED 27K30K35K 90CRI MB M6 WF4 LED 27K30K35K 90CRI MB M6
