Odyssey 5-Blade LED Smart Fan by

2021-03-01_wac lighting design event retail m


Low Price Guarantee Easy Returns
Shipping surcharge: (Why?)

Questions about the Odyssey 5-Blade LED Smart Fan?

Our 100% US-based ALA-certified product specialists can help you find the perfect product

| | Live Chat

Key Features

Ships To Canada
Energy Star Qualified
5 years LED module, lifetime on the motor, and 1 year for all other parts.

It won’t carry you back from Troy, but the Odyssey 5-Blade Smart Fan by WAC Lighting offers a stylish and solid choice in your quest for comfort at home. Held securely to the ceiling above with a bowl-shaped mount, the fixture uses a short downrod to suspend a steel housing to mount its five-blade fan assembly and to house for its damp-listed LED lamping. The fan is easily controlled by a Bluetooth remote and can also be adjusted through its six speeds with the tap of the WAC Smart Fans app, shining down its clear, cyclopean glow from above as it cools your indoor spaces.

WAC Lighting, founded in 1984, has developed a strong reputation for high quality decorative and task lighting. Based in Garden City, New York, WAC Lighting is a leading manufacturer of low voltage, line voltage and LED lighting, including track systems, transformers, lamps, cabinet lighting and recessed downlights.

The Odyssey 5-Blade LED Smart Fan is available with the following:
  • Designed in 2020
  • Material: Steel
  • Number of Blades: 5
  • Blade Pitch: 12 degrees
  • Motor Type: DC
  • Motor Speed: 148 RPM
  • Motor Size: 120 X 15
  • Fan Speeds Forward/Reverse: 6
  • Wall Control On/off Switch Switch
  • Switch Included
  • Fan Airflow (at high speed): 5032 CFM
  • Fan Electricity Use (at high speed): 24 Watts (excludes lights)
  • Fan Airflow Efficiency (at high speed): 237 CFM/Watt
  • Title 20 compliant, Title 24 compliant
  • Energy Star Qualified
  • Sloped ceiling adaptable (0-32)
  • Comes with One 6.00 in. stem/downrod
  • ETL Listed Damp
  • Warranty: 5 years LED module, lifetime on the motor, and 1 year for all other parts.
  • Made In Taiwan
  • Fan Body and Blade Finish: Brushed Nickel, Matte Black, Matte White
  • 48.5 Watt (2200 Lumens) 120 Volt Integrated LED: CRI: 90 Color Temp: 3000K

Compare Brightness:



The amount of light that comes from a bulb, which has commonly been measured in watts. The more lumens, the brighter the bulb.


A measurement of the power delivered to a component of an electric circuit (allowing a one-ampere current to flow through the component under the pressure of 1 volt.)

Bulb Shape

Bulb shapes are denoted with a letter, which describes the shape, and a number, which indicates the size. The number indicates the diameter of the light bulb at its widest part in eighths of an inch.


The part of the bulb that connects to the fixture and its power supply. Bulb bases are denoted with the letter E, and a number which indicates the diameter of the bulb base at its widest part in millimeters.


Indicates how much voltage a bulb can accept via the fixture it's installed in.

Light Color Temperature

The relative color from a light source, measured on the Kelvin temperature scale. Warm light is lower in color temperature (2700-3000 K) and cool, blue light is higher (5000 K).

Average Rated Life

The average amount time that a bulb is expected to last.


CRI = color rendering index. This number, which can go from 0 to 100, measures the ability of a light or bulb accurately renders colors. The higher the number, the better, with most quality bulbs these days measuring at least in the 80s.

  • Blade: Diameter 52"
  • Canopy: Diameter 7"
  • Fixture: Height 10.82", Weight 14Lbs
  • Hanging: Length Adjustable To 15.56"
Energy GuideClick for this product's energy information.

Manufacturer IDs: view

F-005L-BN F-005L-MB F-005L-MW

California Residents: Prop 65 regulations

California Proposition 65

WARNING: This product can expose you to lead, which is known in the State of California to cause cancer, birth defects or other reproductive harm. For more information go to www.p65warnings.ca.gov

Proposition 65 de la Californie

AVERTISSMENT: ce produit peut vous exposer au plomb, ce qui est reconnu par l'État de Californie comme cause de cancer, d'anomalies congénitales ou d'autres domages à la reproduction. Pour plus d'informations, visitez www.p65warnings.ca.gov

Prop. 65 de California

ADVERTENCIA: Este producto puede explonerlo al plomo, lo cual es conocido en el Estado de California como causante de càncer, defectos de namimiento y ostros daños al sistem reproductivo. Para obeneter mayor información, visite www.p65warnings.ca.gov
