Lotus Smart Ceiling Fan

Designed in 2018
One Bluetooth remote included
Motor Speed: 170 RPM
Reverse switch on Control
Fan Airflow (at high speed): 5575 CFM
Fan Electricity Use (at high speed): 17 Watts (excludes lights)
Fan Airflow Efficiency (at high speed): 332 CFM/Watt
Material: Aluminum
Sloped Ceiling Adaptable: Yes
Installation Type: Standard/With Downrod
Control Type: Handheld
Number of Fan Speeds Forward/Reverse: 6
Motor Type: DC
Motor Size: 125 x 30 mm
Includes One 4.50 in. stem/downrods
Lighting Style: Downlight
Location Rating: UL Listed Wet
Title 24 Compliant: This design is compliant with California's expansive Title 24 energy use regulations.
ENERGY STAR® Certified: Rated energy efficient by the Environmental Protection Agency.
OK for Outdoor Use
Assembly Required: No
Warranty: 5 years LED module, lifetime on the motor, and 1 year for all other parts.
Made In China

• Fan Body and Blade Finish: Bronze, Matte White, Titanium Silver, Matte Black

• Color Temperature: 2700, 3000, 3500

Blade: Diameter 54"
Fixture: Height 14.2", Weight 16.7Lbs
Maximum Hanging: Length Adjustable To 12.25"

Compare Brightness:

How many lumens do you need?

More lumens = more light

Lumens
1600
1100
800
450

=

Incandescent	LED	Fluorescent	Halogen
100 W	22 W	23 W	72 W
75 W	18 W	18 W	53 W
60 W	12 W	13 W	43 W
40 W	9 W	11 W	29 W

Output & Wattages based on most common products available for each medium screw-based light bulb. Actual output may vary by product.

Lumens

The amount of light that comes from a bulb, which has commonly been measured in watts. The more lumens, the brighter the bulb.

Wattage

A measurement of the power delivered to a component of an electric circuit (allowing a one-ampere current to flow through the component under the pressure of 1 volt.)

Bulb Shape

Bulb shapes are denoted with a letter, which describes the shape, and a number, which indicates the size. The number indicates the diameter of the light bulb at its widest part in eighths of an inch.

Base

The part of the bulb that connects to the fixture and its power supply. Bulb bases are denoted with the letter E, and a number which indicates the diameter of the bulb base at its widest part in millimeters.

Voltage

Indicates how much voltage a bulb can accept via the fixture it's installed in.

Light Color Temperature

The relative color from a light source, measured on the Kelvin temperature scale. Warm light is lower in color temperature (2700-3000 K) and cool, blue light is higher (5000 K).

Average Rated Life

The average amount time that a bulb is expected to last.

CRI

CRI = color rendering index. This number, which can go from 0 to 100, measures the ability of a light or bulb accurately renders colors. The higher the number, the better, with most quality bulbs these days measuring at least in the 80s.

Click for this product's energy information.

Manufacturer IDs: view

FR-W1809-54L-BZ FR-W1809-54L-MW FR-W1809-54L-TT FR-W1809-54L-27-BZ FR-W1809-54L-35-BZ FR-W1809-54L-27-TT FR-W1809-54L-35-TT FR-W1809-54L-27-MW FR-W1809-54L-35-MW FR-W1809-54L-27-MB FR-W1809-54L-35-MB FR-W1809-54L-MB
